PBG24DCW / PBG24DCG

TECHNA Parking Barrier Gate Operator

Optimize Operations and Maximize Revenue: When connected to myQ software, TECHNA provides insights into traffic flow, peak hours, and vehicle vs. ticket transactions, for data-driven decisions.
Complete Peace of Mind: With a standard battery backup, brushless DC motor, and a direct-drive transmission designed to last up to 10M cycles, TECHNA's durability ensures reliability.
Flexible Arm Bracket: Standard break-a-way or swing-a-way attachments minimize damage from arm strikes.
Highly Visible Design: Programmable red/green LEDs on tower and arm increase visibility, reducing accidental strikes.
Fast & Simple Installation: Change handing with two mechanical adjustments. Five auxiliary relays allow fast loop connection. Modular arms assemble quickly in the field.
Installation and Usage Support: Extensive content library of clear instructions and videos guide installation/maintenance.
Key Metrics at Your Fingertips: On-board counters validate crucial data such as vend count, vehicle count, and total.

Are you a LiftMaster Partner? Log in to purchase.

Overview

Features

Gate Safety and Security

UL Listed

Tested to the most stringent UL 325 industry guidelines. External entrapment protection devices need to be added to meet UL 325 standards. Your Installer will recommend suitable entrapment protection devices for your installation, such as photoelectric or edge sensors.

Gate Safety Sensors

Protect people entering or leaving your gate with safety sensors that stop the gate from closing on obstructions.

Sync

Synchronizes gate operation and eliminates costly trenching; set speed independently if needed.

Gate Power

High Traffic Power

LiftMaster® high-traffic DC powered barrier gate operators with Battery Backup keep traffic flowing and provide easy in and out access 24 hours a day.

Smooth Operation

Get years of reliable use by reducing wear with smooth start/stop operation.

High Traffic Safety

Safeguards access to property with an encrypted signal to offer extended range with Security+2.0.
Can be set to fail open per Fire Department compliance.

Specs

Specifications

Battery Backup	Standard 2 x 12V 7Ah batteries, Optional 2 x 12V 33Ah batteries available	myQ Compatibility	Works with myQ, myQ Facility, or myQ Enterprise
Power	120Vac/230 Vac 1 PH	Wi-Fi	Yes
Speed/Per Second	1.9s Open/Close time	Radio Receiver	LiftMaster Security+ 2.0 , 3-channel receiver up to 64 remote controls (unlimited remotes with 811MX/813MX)
Motor Type	24V DC Motor Drive	Soft Start/Stop	Yes
Warranty	2 Years	Programmable Relays	5 relays, One main board and 4 on the auxiliary boards
Local & Remote Diagnostics	Local log of 50 events correlated to cycle number, unlimited if connected to myQ Facility	Rated Duty Cycle	Continuous Duty

Battery Backup	Standard 2 x 12V 7Ah batteries, Optional 2 x 12V 33Ah batteries available
myQ Compatibility	Works with myQ, myQ Facility, or myQ Enterprise
Power	120Vac/230 Vac 1 PH
Wi-Fi	Yes
Speed/Per Second	1.9s Open/Close time
Radio Receiver	LiftMaster Security+ 2.0 , 3-channel receiver up to 64 remote controls (unlimited remotes with 811MX/813MX)
Motor Type	24V DC Motor Drive
Soft Start/Stop	Yes
Warranty	2 Years
Programmable Relays	5 relays, One main board and 4 on the auxiliary boards
Local & Remote Diagnostics	Local log of 50 events correlated to cycle number, unlimited if connected to myQ Facility
Rated Duty Cycle	Continuous Duty
